The Foundation for Below-Grade Moisture Resistance.
With a large offering of below grade and under-slab insulating products, Insulfoam and R-Tech® brand expanded polystyrene (EPS) and graphite polystyrene (GPS) insulation products are engineered to stand the test of time. Designed to insulate concrete, foundation walls or slab while offering the ability to protect waterproofing or damp proofing (especially during back filling), Insulfoam Below Grade Foundation Insulation is widely used for both commercial and residential applications, including:
Why Insulate Below-Grade?
It’s simple. Below-grade insulation is important both for the longevity of your structures and for the earth. Lack of foundation insulation on below-grade and under slab projects can account for up to 25% of a structure’s total heat loss. Insulating properly below-grade, can also combat heat loss and help each structure reduce heating and cooling bills by 10-20%.
Standard Insulfoam Below Grade Insulation
Available in custom sized panels and blocks, for ease of material handling. Available in widths up to 4′, lengths up to 16′ and thicknesses up to 40″, InsulGrade is also available in nominal compressive strengths of 10-60 psi. Customize properties to make Insulfoam products suitable for your precise project needs.
R-Tech Insulation, Including Fanfold Bundles
R-Tech features a premium factory-applied polymeric facer that is virtually impervious to moisture, helps keep water from entering the insulation and away from concrete and slabs. Available in 4’x8′ panels, thicknesses starting at 3/8″, with compressive strengths from 10-60 psi, contractors can pick the right thickness and compressive strength for each job. For reduced labor choose R-Tech fanfold protection board,available in lightweight 200 sq. ft. bundles available in thicknesses of 38″, 1/2″, and 3/4″.
Insulfoam DB – Drainage Board
Manufactured from any standard Insulfoam product, DB’s factory-applied channels and filtration facers help drain and reduce hydrostatic pressure. Available in thicknesses up to 5″.
Why are Insulfoam below-grade insulation products the best choice?
Insulfoam EPS & GPS outperforms XPS below-grade insulation for less material cost! Consider these three criteria and you’ll agree that Insulfoam is the best insulation choice for your project:
- Moisture Absorption: Field studies prove that EPS absorbs less moisture than XPS in the long term.
- R-Value Stability: With the highest R-value per dollar, EPS R-Value doesn’t degrade over time. This is why Insulfoam warrants 100% of R-Value, even during freeze-thaw cycles. XPS only warrants up to 90% of its R-value, and the warranty is regularly void in the case of water ponding or immersion (critical for below-grade applications).
- Compressive Strength: Seven standard compressive strengths available, for up to 40% material cost reduction over XPS.
- A comparison of physical properties and offerings of Platinum GPS & XPS rigid insulations.
- View the results from a 15 Year Moisture Resistance Study between EPS & XPS.
Below Grade Insulation Overview
- Insulfoam Below Grade Overview Brochure: Features & Performance Benefits Over Other Insulations
InsulFoam® Insulation Products
- Insulfoam EPS Below Grade Insulation Products
- Insulfoam Platinum & R-Tech Platinum GPS Below Grade Insulation
- R-Tech Below Grade Insulation & Waterproof Protection Board – EPS with laminated polymeric facers, with EPS standard or GPS Platinum core
- R-Tech Fanfold Protection Board – 2 Square bundles of R-Tech, available with EPS standard or GPS Platinum core
- InsulFoam DB – Drainage Board, also available faced and with Platinum cores in some locations
Alaska Only Below Grade Insulation Products
Standard InsulFoam® Below Grade EPS Insulation
- InsulFoam EPS Product Selector Guide
- InsulFoam I – 10 psi
- InsulFoam VIII – 15 psi
- InsulFoam II – 20 psi
- InsulFoam IX – 25 psi
- InsulFoam IX+ – 30 psi
- InsulFoam XIV – 40 psi
- InsulFoam XV – 60 psi
Platinum GPS Insulation:
InsulFoam® EPS with laminated polymeric facers
- R-Tech® – Product Selector Guide
- R-Tech I – 13 psi
- R-Tech X – 15 psi
- R-Tech IV – 25 psi
- R-Tech VI – 40 psi
- R-Tech VII – 60 psi
R-Tech Platinum GPS Insulation:
- Under Slab Design Considerations
- Technical Bulletin #9 – Insulfoam EPS Below Concrete Slab Applications
- Technical Bulletin #15 – Insulfoam EPS in Cold Temperature Applications
- Technical Bulletin #21 – R-Tech Freeze Thaw Environmental Cycling
- Technical Bulletin #22 – 15-Year In-Situation Performance of Below Grade Insulations
- Technical Bulletin #23 – Physical Properties of Insulfoam EPS
- Technical Bulletin #24 – Coefficient of Thermal Expansion
- Technical Bulletin #26 – EPS Compatible Adhesives
- Frequently Asked Questions re: 15 year study
- Frequently asked questions re: R-TECH IV
